XTY-400KL10060 is one of the most popular models in KL series with high-quality and competitive price.
Peculiar direct-crossed combination of motor and pump assures 100% concentricity, instead of the common couple connection to extend the lifespan of the pump.
Pressure:40 tons
Feed Opening Size(L*H):1000*500mm
Baling Chamber Height:1500mm
Bale Size(L*W*H,H is adjustable):1000*600*(300-1000)mm
Bale Weight:60-180kgs
Power:7.5kw
Machine Weight:1700kgs
Machine Overall Dimension:1480*1000*3400mm
